HPE Apollo 4200 Gen10 Plus Service Manual

24 SFF server
ItemItem DescriptionDescription
1 iLO Service Port
2 SFF hot-plug drives
3 USB 3.0 port
Front panel LEDs and buttonsFront panel LEDs and buttons
ItemItem DescriptionDescription StatusStatus
1 Health LED
Solid green = Normal
Flashing green (1 flash per sec) = iLO is rebooting
Flashing amber = System degraded
Flashing red (1 flash per sec) = System critical
2 Power On/Standby button and system
power LED
Solid green = System on
Flashing green (1 flash per second) = Performing power on sequence
Solid amber = System in standby
Off = No power present
3 NIC status LED
Solid green = Link to network
Flashing green (1 flash per second) = Network active
Off = No network activity
1
1
2
3
1
HPE Apollo 4200 Gen10 Plus Server Maintenance and Service Guide 57

HPE Apollo 4200 Gen10 Plus Specifications

General

Form Factor	2U
Number of Memory Slots	32 DIMM slots
Remote Management	HPE iLO 5
Processor	Intel Xeon Scalable Processors (3rd Gen)
Memory	DDR4
Storage	SAS, SATA, NVMe
Network	FlexibleLOM, PCIe stand-up cards
Power Supply	1600W
Drive Bays	Up to 28 SFF or 16 LFF drive bays
Expansion Slots	Up to 8 PCIe 3.0 slots
GPU Support	Yes, supports GPUs
Operating System Support	Windows Server, RHEL, SLES, VMware
