System board PCIe slots 7 flashes
Power backplane 8 flashes
Storage backplane 9 flashes
Power supply 10 flashes
PCIe expansion cards installed in riser board 11 flashes
Chassis 12 flashes
GPU card 13 flashes
SubsystemSubsystem LED behaviorLED behavior
Rear panel componentsRear panel components
ItemItem DescriptionDescription
1 Primary riser or drive cage 4 (riser shown)
2 Secondary/tertiary riser or drive cage 5 (riser shown)
3 Hot-plug power supply bay 1 (standard)
4 Hot-plug power supply bay 2 (optional)
5 COM port
6 USB 3.0 connectors
7 iLO Management port
8 Video connector
9 OCP NIC 3.0
