To replace the component, reverse the removal procedure.
Removing and replacing the PCI riser cageRemoving and replacing the PCI riser cage
WARNING: WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before
touching them.
CAUTION: CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning
any installation, removal, or replacement procedure. Improper grounding can cause electrostatic discharge.
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the components included with the hardware kit.
ProcedureProcedure
1. Power down the server.
2. Remove the server from the rack .
3. Place the server on a flat, level surface.
4. Remove the complete access panel .
5. If expansion boards with internal cabling are installed on the PCI riser cage, disconnect all internal cables from the expansion boards
to remove the cage from the server.
6. Remove the PCI riser cage.
Primary slot
