which they were removed.
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Remove the server from the rack .
4. Remove the access panel.
5. Remove the air baffle.
6. Remove drive cage 2.
7. Remove the cable arm.
8. Remove the brackets from the cable arm and then remove the cables.
