Components included with the hardware kit
T-10 screwdriver
ProcedureProcedure
1. Power down the server.
2. Remove the server from the rack .
3. Place the server on a flat, level surface.
4. Remove the complete access panel .
5. If you are removing an expansion board installed in the PCI riser cage, remove the riser cage.
6. Disconnect any cables that are connected to the expansion board.
7. Remove the expansion board.
Expansion board removal from an onboard expansion slot
Expansion board removal from the PCI riser cage
To replace the component, reverse the procedure.
Removing and replacing a type -a storage controllerRemoving and replacing a type -a storage controller
WARNING: WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components
to cool before touching them.
