HPE Apollo 4200 Gen10 Plus Service Manual

ItemItem DescriptionDescription StatusStatus
1 iLO port 1 link LED Green = Network link
Off = No network link
2 iLO port 1 activity LED Solid green = Link to network
Flashing green = Network active
Off = No network activity
3 UID LED Solid blue = Activated
Flashing blue:
1 flash per second = Remote management or firmware upgrade in progress
4 flashes per second = iLO manual reboot sequence initiated
8 flashes per second = iLO manual reboot sequence in progress
Off = Deactivated
4 Power supply LED (bay 2) Solid green = Normal
Off = One or more of the following conditions exists:
Power is unavailable.
Power supply failed
Power supply is in standby mode.
Power supply error
5 Power supply LED (bay 1) Solid green = Normal
Off = One or more of the following conditions exists:
Power is unavailable.
Power supply failed
Power supply is in standby mode.
Power supply error
System board componentsSystem board components
The components shown in this section are associated with the ProLiant XL420 Gen10 Plus server server board.
ItemItem DescriptionDescription
1 Internal USB 3.0 connector
2 Front USB for iLO connector
3 TPM 2.0 connector
1
HPE Apollo 4200 Gen10 Plus Server Maintenance and Service Guide 60

HPE Apollo 4200 Gen10 Plus Specifications

General

Form Factor	2U
Number of Memory Slots	32 DIMM slots
Remote Management	HPE iLO 5
Processor	Intel Xeon Scalable Processors (3rd Gen)
Memory	DDR4
Storage	SAS, SATA, NVMe
Network	FlexibleLOM, PCIe stand-up cards
Power Supply	1600W
Drive Bays	Up to 28 SFF or 16 LFF drive bays
Expansion Slots	Up to 8 PCIe 3.0 slots
GPU Support	Yes, supports GPUs
Operating System Support	Windows Server, RHEL, SLES, VMware
