4. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
5. Remove the server from the rack .
6. Place the server on a flat, level work surface.
7. Remove the access panel.
8. If necessary, remove the PCI riser cage.
9. Remove the boot device.
10. Remove the failed drive from the boot device.
To replace the component, reverse the removal procedure.
Relocating the M.2 drive retaining latchesRelocating the M.2 drive retaining latches
ProcedureProcedure
1. If your spare kit includes an 80 mm replacement drive, remove the retaining latch from its current location.
2. Install the retaining latch at the 80 mm drive location.
Removing and replacing a DIMMRemoving and replacing a DIMM
WARNING: WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components
to cool before touching them.
CAUTION: CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning
any installation, removal, or replacement procedure. Improper grounding can cause electrostatic discharge.
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the components included with the hardware kit.
ProcedureProcedure
1. Power down the server.
2. Remove the server from the rack .
3. Place the server on a flat, level surface.
4. Remove the complete access panel .
5. Remove the air baffle.
6. Remove the DIMM.
