Removing and replacing Removing and replacing drive cage 3drive cage 3
WARNING: WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components
to cool before touching them.
CAUTION: CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning
any installation, removal, or replacement procedure. Improper grounding can cause electrostatic discharge.
ProcedureProcedure
1. Power down the server.
2. Remove the server from the rack .
3. Place the server on a flat, level surface.
4. Remove the complete access panel .
5. Do one of the following:
a. If you have the eight SFF drive cage 3 installed, remove the air baffle.
b. If you have the four LFF drive cage 3 installed, proceed to the next step.
CAUTION:CAUTION:
When removing drive cage 3 from the server, be sure to carefully feed the cables through the openings at the rear
of the drive cage.
6. Disconnect cables connected to the backplane.
