Procedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
• If the server is in tower mode:
Position the tower server for hardware configuration.
• If the server is in rack mode: Remove the server from the rack.
5.
Remove the front bezel.
6. Remove the access panel.
7. If installed,
remove the air bale.
8.
Remove the Phillips screw and the hex nut.
9. Remove the iLO dedicated network port blank.
Hardware options installation
71
