11. Remove the drive.
To replace the component, reverse the removal procedure.
Removing and replacing an LFF hot-plug drive
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all
bays are populated with either a component or a blank.
Procedure
1. Back up all server data on the drive.
2. Remove the front bezel.
3. Determine the status of the drive from the drive LED definitions.
4. Remove the drive.
Removal and replacement procedures 39
