11. Remove the front I/O cap:
a. Pull the cap from both the ends.
b. Remove the cap from the I/O cable.
12. Remove the front I/O assembly from the rear panel.
To replace the component, reverse the removal procedure.
Removing and replacing the EMI shield
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all
bays are populated with either a component or a blank.
Procedure
1. Power down the server.
2. Remove all power:
Removal and replacement procedures 45
