◦ Extend the server from the rack.
◦ Remove the server from the rack.
5. Remove the front bezel.
6. Remove the access panel.
7. If installed, remove the air baffle.
8. Remove the Smart Storage Battery:
a. Disconnect the battery cable.
b. Press the release latch on one of the battery holders.
c. Lift one end of the battery.
d. Remove the entire battery from the holders.
To replace the component, reverse the removal procedure.
Removing and replacing the Smart Storage Battery
holders
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and internal
system components to cool before touching them.
Prerequisites
Before you perform this procedure make sure that you have a small flat-bladed, nonconductive tool
available.
Procedure
1. Power down the server.
2. Remove all power:
60 Removal and replacement procedures
