HPE STOREONCE 5500

• The StoreOnce 3540 model is supplied with twelve 4 TB disks installed.
• The StoreOnce 3520 model is supplied with twelve 2 TB disks installed.
The base configuration for both models uses 50% of the available capacity (24 TB or 12 TB). If configured
in the factory for the full capacity of 48 TB (3540 model) or 24 TB (3520 model), all storage will already be
licensed. If not factory configured, the license entitlement will be delivered to the user via email.
IMPORTANT:
When increasing storage capacity from 50% to 100%, the only installation and configuration task is
to apply the license for the additional capacity.
HPE StoreOnce 5100 System
Front and rear views
3 421
Figure 16: HPE StoreOnce 5100 System front view
1 NIC status LED 2 Health LED
3 Power on/standby button and system power
LED
4 UID button LED
1
2
3
4
1
5
6
4
4
1
iLO
PS2
PS1
1 2 3 4 5 6 7 8 9
10111213141516171819
Figure 17: HPE StoreOnce 5100 System rear view
1 Slot 1, available for Optional Hardware 2 Slot 2, SAS expander card
3 Slot 3, RAID controller card 4 Slot 4, available for Optional Hardware
Table Continued
HPE StoreOnce 5100 System 73
