Optional PCIe cards
StoreOnce Optional Hardware with StoreOnce 35xx and
5xxx models
StoreOnce software supports the addition of 10 GbE Network and/or Fibre Channel PCIe cards for the
StoreOnce models listed in the table below.
Table 14: PCIe slot configuration options for StoreOnce Systems
Product Name PCIe slots available for
additional cards
Card choices
HPE StoreOnce 3100 System None The addition of 10 GbE and/or
FC cards is not supported
HPE StoreOnce 3500 Series Four: slots 1, 4, 5 and 6 10 GbE SFP or 10 GbE-T
Network card
8 Gb or 16 Gb Fibre Channel
card
HPE StoreOnce 5100 System Four: slots 1, 4, 5 and 6 10 GbE SFP or 10 GbE-T
Network card
8 Gb or 16 Gb Fibre Channel
card
HPE StoreOnce 5500 System Four: slots 1, 4, 5 and 6 10 GbE SFP or 10 GbE-T
Network card
8 Gb or 16 Gb Fibre Channel
card
PCIe slot allocation at delivery
If you have ordered additional PCIe cards with the base product, the StoreOnce System will have the
correct cards installed in the correct PCIe slots, and they will be configured and licensed when the
product is supplied. You must insert the SFP transceivers, if required, attach the appropriate cables and
connect to the network or FC SAN.
IMPORTANT:
For detailed information about installing additional PCIe cards after initial delivery, see the
StoreOnce Optional Hardware Installation and Configuration Guide.
The following drawing illustrates the rear view of a StoreOnce 5100 System. Remember that:
• The cards installed in each slot are determined by your purchase order, so any illustrations are
examples only.
• The PCIe cards must be installed in the correct slot sequence.
76 Optional PCIe cards
