hpmont HD09-S Series User Manual

Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 104 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
F20.36 Fault type of first time
E0028: SCI communication time-out
E0029: SCI communication error
0 1 *
F20.22
Preset frequency of the
latest failure
0.00 - 150.00Hz 0.00Hz 0.01Hz *
F20.23
Running frequency of the
latest failure
0.00 - 150.00Hz 0.00Hz 0.01Hz *
F20.24
DC bus voltage of the
latest failure
0 - 999V 0V 1V *
F20.25
Output voltage of the
latest failure
0 - 999V 0V 1V *
F20.26
Output current of the
latest failure
0.00 - 99.99A 0.00A 0.01A *
F20.27
Input terminal status at the
latest fault
0 - 0xF 0 1 *
F20.28
Output terminal status at
the latest fault
0 - 0xF 0 1 *
F20.29
Interval time of the latest
failure
0.0 - 6553.5h 0.0h 0.1h *
F20.31 Fourth fault interval 0.0 - 6553.5h 0.0h 0.1h *
F20.33 The third fault interval 0.0 - 6553.5h 0.0h 0.1h *
F20.35
Interval time of the second
time failure
0.0 - 6553.5h 0.0h 0.1h *
F20.37
Interval time of the first
time failure
0.0 - 6553.5h 0.0h 0.1h *
F23: PWM Controlling Parameter
F23.00 Carrier frequency setting 1 - 8kHz 8kHz 1kHz
×
F23.01
Carrier frequency is
automatically adjusted
0: Automatic adjustment of carrier
frequency is forbidden
1: Enable automatic adjustment of
carrier frequency
1 1
×
F23.02
PWM over modulation
enabled
0: Invalid
1: Valid
1 1
×
F23.03 PWM modulation mode
0: Two-phase modulation / three-phase
modulation switching
1: Three-phase modulation
1 1
×
F23.04
PWM modulation mode
switching point 1
Type confirmed - F23.05 - 2Hz
Type
confirmed
0.01Hz
×
