hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 103 -
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
1: Enable inverter overload protection
to shield motor overload protection
2: Shield inverter overload protection,
enable motor overload protection
3: Shield inverter overload protection,
motor overload protection
F20.10
Detecting datum for
output phase fault
0 - 50% 20% 1%
×
F20.11
Detecting time for output
phase fault
0.00 - 20.00s 3.00s 0.01s
×
F20.18 Automatic reset number 0 - 100 0 1
×
F20.19 Automatic reset interval 2.0 - 20.0s/times
5.0
s/times
0.1
s/times
×
F20.21 Fifth (last) type of fault
-Lu-: DC bus undervoltage
E0001: Inverter output over current
(Acc. process)
E0002: Inverter output over current
(Dec. process)
E0003: Inverter output over current
(constant speed process)
E0004: DC bus overvoltage (Acc.
process)
E0005: DC bus overvoltage (Dec.
process)
E0006: DC bus overvoltage (constant
speed process)
E0007: Stall overvoltage
E0009: Heatsink overheat
E0010: Braking unit failure
E0012: Parameters auto-tuning fault
E0014: Fault of current detection circuit
E0016: Fault of output phase
E0017: Inverter overload
E0019: Motor overload
E0021: Access fault of control board
EEPROM
E0022: Operation keypad EEPROM read
and write problems
E0023: Parameter setting error
E0024: External equipment failure
0 1 *
F20.30 The fourth fault type 0 1 *
F20.32 The third fault type 0 1 *
F20.34 Fault type of second time 0 1 *
