hpmont HD09-S Series - Fault Protection Parameters (F20)

Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 102 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
F19.11
Set the frequency below
the zero-frequency
threshold action selection
0: Run according to the frequency
command
1: Keep stop status, inverter has no
output
2: Press zero frequency threshold to run
3: Run at zero frequency
0 1
×
F19.18
Overvoltage stalling
options
0 - 1.000 0.500 0.001
○
F19.19
Overvoltage speed lose
point
0 - 1200V
Type
confirmed
1V
×
F19.20
Automatic current limiting
gain
0 - 1.000 0.500 0.001
○
F19.21
Automatic current limit
level
20.0 - 200.0% 150.0% 0.1%
×
F19.22
Automatic current limiting
integral time constant
0 - 1.000 0.020 0.001
○
F19.23
Power-on instantaneous
terminal detection
0: Rising edge effective
1: Electrical level
0 1
○
F19.24
Action voltage of brake
unit
220V inverter: 380 - 450V 380V 1V
×
380V inverter: 630 - 750V 720V 1V
×
F19.39 Input voltage selection
Unit: Model 380V input voltage
selection
0: 380 - 460V
1: 260 - 460V
2: 200 - 460V
Ten: Model 220V input voltage
selection
0: 200 - 240V
1: 120 - 240V
00 1
×
F19.44 LCD display time 0.0 - 999.9min 5.0min 0.1min
○
F20: Fault Protection Parameter
F20.00 Overload alarm selection
Unit / ten / hundred / one thousand:
Reserved
Ten thousand place: Overload
protection choice
0: Enables inverter overload protection
and motor overload protection
00000 1
×
