Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 52 - HD09-S Series User Manual V1.1
Ref. Code Function Description Setting Range [Default]
43: Emergency stop.
The inverter decelerates to stop after it receives the terminal command. The Dec. time is set according to
F03.17 (Dec. time of emergency stop).
44,45: The external input fault normally open / closed.
The inverter can detect the fault signal of the external device through the terminals. Fault signal is
normally open or normally closed.
After receiving an external fault signal, converter will stop freely down, at the same time, display external
equipment failure (E0024).
46: External reset input.
When the fault alarm is occurred in inverter, this DI terminal can reset fault.
It has the same function as the keypad or key reset function.
50: Counter reset signal input.
51 function should be used together to reset converter built-in counter.
51: Counter trigger signal input.
Built-in counter counts pulse input port, when power off , the current count value can be stored.
The highest frequency pulse: 200Hz. Specific see F15.37, F15.38.
53: Pulse frequency input (DI4).
DI4 terminal can receive the pulse signal as a frequency setting, the relationship between input pulse
frequency and the set frequency see F05.01 - F05.04.
86: Terminal stop DC brake.
After the inverter receives the stop command, if the stop mode is Dec. stop + DC brake (F02.13 = 2) and
the running frequency is lower than the starting frequency of stopping DC braking (F02.16), the inverter
will start DC brake.
The braking current is set by F02.04. The braking time is the longer time between the terminal function
holding time and the stopping DC braking time (F02.18).
F15.12 Terminal UP / DOWN of the rate of Acc. and Dec. 0.00 - 99.99 [1.00Hz/s]
Define DI terminals as the UP / DN terminals (17/18 function), modified chaneing rate of set frequency.
F15.13 Terminal detection interval time 0 - 2 [0]
0: 2ms.
1: 4ms.
2: 8ms.
F15.14 Number of terminal detection filter 0 - 10000 [4]
Delay, confirm DI terminal signals to prevent DI terminal misoperation.
