hpmont HD09-S Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09-S Series User Manual V1.1 - 87 -
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
d00.45 Process PID feedback Actual *
d00.46 Process PID tolerance Actual *
d00.47 Process PID integral item Actual *
d00.48 Process PID output Actual *
d00.49 External counting value Actual *
d00.50 Input terminal status Actual *
d00.51 Output terminal status Actual *
d00.55 Total time at power-on Actual *
d00.56 Total time at operation Actual *
d00.57
High bit of motor total
energy consumption
Actual *
d00.58
Low bit of motor total
energy consumption
Actual *
d00.59
High bit of energy
consumption at this time
running
Actual *
d00.60
Low bit of energy
consumption at this time
running
Actual *
d00.61 Present fault Actual *
F00: Basic Parameter
F00.01 Control mode selection
0: V/f control without PG
2: PG without vector control
0 1
×
F00.06 Max. output frequency 50.00 - 400.00Hz 50.00Hz 0.01Hz
×
F00.08 Max. operating frequency 0.00Hz - F00.06 50.00Hz 0.01Hz
×
F00.09 Min. operating frequency 0.00Hz - F00.08 0.00Hz 0.01Hz
×
F00.10
Frequency setting access
selection
0: Keypad digital setting
1: Terminal digital setting
2: SCI communication setting
3: Analogue setting
4: Terminal impulse setting
6: AI1 terminal setting
11: Keypad potentiometer setting
0 1
×
F00.11
Operation command
access selection
0: Keypad operation command
1: Terminal operation command
2: SCI communication command
0 1
×
