Shenzhen Hpmont Technology Co., Ltd Chapter 7 Elevator Application Guidance
HD5L Series Controller User Manual ―95―
Table 7-2 Special function code setting table of terminal MS run
Code Name Recommended value Remark
F00.05 Operating mode 2 Terminal MS control
F02.02 Retention time of start zero-speed 0.5s According the situation of running
contactor and brake at motor start
& stop to adjust.
F02.06 Retention time of stop zero-speed 0.5s
F03.00 Acceleration speed 0.700m/s
2
According the elevator speed and
running effect to set.
F03.01 Start Acc jerk 0.350m/s
3
F03.02 End Acc jerk 0.600m/s
3
F03.03 Deceleration speed 0.700m/s
2
F03.04 Start Dec jerk 0.600m/s
3
F03.05 End Dec jerk 0.350m/s
3
F03.06 Inspection Acc speed 0.200m/s
2
F03.07 Inspection Dec speed 1.000m/s
2
F03.13 Stop Dec jerk 0.350 m/s
3
F05.00 Multi-speed 0 0
As deisgn
F05.01 Multi-speed 1 Re-leveling speed
F05.02 Multi-speed 2 Creeping speed
F05.03 Multi-speed 3 Battery driven speed
F05.04 Multi-speed 4 Inspection speed
F05.05 Multi-speed 5 Normal low speed
F05.06 Multi-speed d 6 Normal mid speed
F05.07 Multi-speed 7 Normal high speed
F06.00 Pre-torque selection 4 No weighing auto-compensation
F06.14 No weighing current coefficient 3000 Debug according to the running
effect; Increase the three
parameter values in the motor non
oscillatory situation.
F06.15 No weighing speed-loop KP 2000
F06.16 No weighing speed-loop KI 2000
F12.01 DI1 terminal function 1 Controller enabled (EN)
F12.02 DI2 terminal function 2 UP
F12.03 DI3 terminal function 3 DN
F12.04 DI4 terminal function 4 MS1
F12.05 DI5 terminal function 5 MS2
F12.06 DI6 terminal function 6 MS3
F12.15 DO1 terminal function 2 Controller is running
F12.16 DO2 terminal function 3
Controller is at zero-speed
running
F12.17 RLY1 terminal function 14 Controller fault
F16.07 Multi-sped inspection select 4 Multi-speed inspection select
7
