Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD5L Series Controller User Manual ―55―
6.1.2 Group D01 Drive State Parameters
Code Name Description Range
【
factory setting
】
D01.00 Control mode
【
actual value
】
Display the cotrol mode.
D01.01 Setting speed (m/s)
【
actual value
】
Display the setting speed.
D01.02 Setting speed (after acceleration/deceleration) (m/s)
【
actual value
】
Display the speed which is disposed by acceleration/deceleration S curve.
D01.03 Feedback speed (m/s)
【
actual value
】
Display the elevator’s actual speed.
D01.04 Setting frequency
【
actual value
】
Display the setting frequency.
D01.05 Setting frequency (after acceleration/deceleration)
【
actual value
】
Display the frequency (after acceleration/deceleration).
D01.06 Output frequency
【
actual value
】
Display the output frequency.
D01.07 Setting Rpm
【
actual value
】
Display the setting Rpm.
D01.08 Running Rpm
【
actual value
】
Display the running Rpm.
D01.09 Reserved
D01.10
Output voltage
【actual value】
Display the output voltage.
D01.11
Output current
【actual value】
Display the output current.
D01.12
Output torque
【actual value】
Display the output torque which is the relative percentage of the motor rated torque.
D01.13
Output power
【actual value】
Display the output power which is the relative percentage of the motor rated power.
D01.14
DC bus voltage
【actual value】
Display the DC bus voltage.
D01.15－D01.16 Reserved
