Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD5L Series Controller User Manual ―57―
6.1.4 Group D03 Running State Parameters
Code Name Description Range
【
factory setting
】
D03.00 Heatsink temperature
【
actual value
】
Display heatsink temperature.
D03.01 Input terminal state
【
actual value
】
Display input terminal state. Each bit(binary) of this function parameter stands for different physical
sources which are in the below table.
• 0: Multi-function input terminals are not connected with common terminals.
• 1: Multi-function input terminals are connected with common terminals.
Bit11 Bit10 Bit9 Bit8 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
DI12 DI11 DI10 DI9 DI8 DI7 DI6 DI5 DI4 DI3 DI2 DI1
123
D03.02
Output terminal state
【actual value】
Display output terminal state. Each bit(binary) of this function parameter stands for different physical
sources which are in the below table.
• Positive logic: 0 stands for invalid while 1 stands for valid.
• Negative logic: 0 stands for valid while 1 stands for invalid.
Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
RLY4 RLY3 RLY2 RLY1 DO2 DO1
123
D03.03 MODBUS state
【
actual value
】
Display MODBUS communication state.
0: Normal.
1: Communication timeout.
2: Incorrect data frame head.
3: Incorrect data frame checking.
4: Incorrect data frame content.
D03.04 Total time at power-on
【
actual value
】
D03.05
Total running time
【actual value】
D03.04 display total time at power-on; D03.05 displays total running time. The unit is hour.
D03.06
Running times
【actual value】
Display the running times of the controller.
D03.07
Present fault
【actual value】
Display the present fault.
