6.2.17 Group F16 Enhance Function Parameters
Code Name Description Range
factory setting
F16.00 Zero-speed running signal delay time 0.00
10.00
0.30s
It defines the delay time from the controller at zero-speed run state to zero-speed run signal output.
F16.01 Zero-speed signal delay time 0.00
10.00
0.30s
It defines the delay time from the controller at zero-speed state to zero-speed signal output.
F16.02 Current keep time after stop command 0
9999
0ms
To eliminate the motor current noise at stop, when the brake is over, the cut-off run signal will reduce
the current to zero after the time defined by F16.02.
F16.03 Fan control mode 0
2
0
It defines the fan control mode. If there is over-heat protection, the fan will run all the time.
0: Auto stop.
• The fan runs all the time when the controller is in running state. After the controller stops for the
time set by F16.04, the fan will auto stop if there isn’t over-heat protection.
1: Immediately stop.
• The fan runs all the time when the controller is in running state, but stops when the controller stops.
2: Run when power on.
• The fan runs continuously after the controller is switched on.
F16.04 Fan keep time 0.0
600.0
30.0s
F16.05 Brake unit action voltage 380
750V
【Depend on controller model】
For 380V voltage class controller, the braking voltage range is 630－750V.
For 220V voltage class controller, the braking voltage range is 380－450V.
Note: The braking action enable only in the controller run state.
Contator fault detect time
F16.07 Multi-speed inspection select 0
7
0
When the digital input terminals are not enough, the combinations of MS1－MS3 can achieve the
inspection run.
• When there is digital input terminal set as inspection terminal INS (No. 7 function), only need set
F16.07 as 0 to enter terminal inspection run.
• When there isn’t digital input terminal set as inspection terminal INS (No. 7 function), the inspection
run can be achieved via the combination of MS1－MS3.
• When the value of MS1－MS3 is equal to the value of F16.07, enter MS inspection run at MS
run speed (F05.00－F05.07).
Note: When the MS run speed (F05.00
F05.07) exceeds 0.630m/s, run at 0.630m/s.
F16.08 Zero-speed threshold 0.001
0.010
0.003m/s
When the present run speed does not exceed F16.08, the system run speed will be condidered as 0.
After zero-speed delay signal, the zero-speed signal will be output.
F16.09 Selection at motor overheat fault 0,1
0
0: When detect that the motor is overheated, report E0020 (motor overheated) after motor stop.
1: When detect that the motor is overheated, report E0020 (motor overheated) at once.
F16.10 The coefficient of frequency demultiplication of
HD-PG9-SC-FD
1
256
1
To set the coefficient of frequency demultiplication of HD-PG9-SC-FD.
F16.11
F16.24 Reserved
6
