Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―56― HD5L Series Controller User Manual
6.1.3 Group D02 Analogue State Display Parameters
Code Name Description Range
factory setting
D02.00 AI1 voltage
actual value
Display AI1 input voltage.
D02.01 AI1 voltage (after disposal)
actual value
Display A1 input voltage which is disposed by the gain, bias and filter.
D02.02 AI2 voltage
actual value
Display AI2 input voltage. When AI2 selects current input, the corresponding relations are:
- 10.00V corresponds to 0mA, and 10.00V corresponds to 20mA.
D02.03 AI2 voltage (after disposal)
actual value
Display A2 input voltage which is disposed by the gain, bias and filter.
D02.04 AI3 voltage
actual value
Display AI3 input voltage. When AI3 selects current input, the corresponding relations are:
- 10.00V corresponds to 0mA, and 10.00V corresponds to 20mA.
D02.05 AI3 voltage (after disposal)
actual value
Display A3 input voltage which is disposed by the gain, bias and filter.
D02.06 AI4 voltage
actual value
Display AI4 input voltage. When AI4 selects current input, the corresponding relations are:
- 10.00V corresponds to 0mA, and 10.00V corresponds to 20mA.
D02.07 AI4 voltage (after disposal)
actual value
Display A4 input voltage which is disposed by the gain, bias and filter.
D02.08 AO1 output
actual value
Display AO1 output. When AO1 selects current output, the corresponding relations are:
0V corresponds to 0mA, and 10.00V corresponds to 20mA.
D02.09 AO2 output
actual value
Display AO2 output. When AO2 selects current output, the corresponding relations are:
0V corresponds to 0mA, and 10.00V corresponds to 20mA.
