Shenzhen Hpmont Technology Co., Ltd Chapter 5 Operation Instructions
HD5L Series Controller User Manual ―43―
Chapter 5 Operation Instructions
• Only when the controller terminal cover has been fitted can you switch on AC power source. Do not
remove the cover after power is switched on.
• Ensure the motor and the mechnical device are in the use application before the controller starts.
• Keep away from the controller if the auto-restart function is enabled at power outage.
• If changed the main control PCBA, you should correctly set the parameters before operating.
• Do not check or detect the signal during the controller operation.
• Do not randomly change the controller parameter setting.
• Please thoroughly complete all control debugging and testing, make all adjustments and conduct a full
safety assessment before switching the run command source of the controller.
• Do not touch the energy-depletion braking resistor due to the high temperature.
5.1 Function Description
Note:
1. In the following sections, you may encounter control, running and state of the controller
description many times.
2. Please read this section carefully. It will help you to correctly understand and use the functions
to be discussed.
5.1.1 Operation Mode
The operation mode defines how the controller receives run commands (start or stop command).
There are four operation modes which can be selected through function parameter F00.05.
Panel control: The run command is controlled by and keys of the panel; and the
run speed is set by F00.07.
Terminal analogue control: The run command is controlled by UP and DN of the terminal; and
the run speed is set by AI1
－
AI4 analogue input terminals.
Terminal speed control: The run command is controlled by UP and DN of the terminal; and the
run speed is set by MS1
－
MS3 multi-step speed terminal combination.
Communication speed control: The run command and the run multi-step speed are set by PC
communication.
5
