Shenzhen Hpmont Technology Co., Ltd Appendix B Communication Protocol
HD5L Series Controller User Manual －139－
2. State parameter
The high-bytes address of control state register is 0x33 and the low-bytes address is as following:
Low-bytes address Group No. Low-bytes address Group No.
0x00 D00.00 0x01 D00.01
0x02 D00.02 0x03 D00.03
0x04 D00.04 0x05 D00.05
0x06 D00.06 0x07 D01.00
0x08 D01.01 0x09 D01.02
0x0a D01.03 0x0b D01.04
0x0c D01.05 0x0d D01.06
0x0e D01.07 0x0f D01.08
0x10 D01.09 0x11 D01.10
0x12 D01.11 0x13 D01.12
0x14 D01.13 0x15 D01.14
0x16 D01.15 0x17 D01.16
0x18 D02.00 0x19 D02.01
0x1a D02.02 0x1b D02.03
0x1c D02.04 0x1d D02.05
0x1e D02.06 0x1f D02.07
0x20 D02.08 0x21 D02.09
0x22 D03.00 0x23 D03.01
0x24 D03.02 0x25 D03.03
0x26 D03.04 0x27 D03.05
0x28 D03.06 0x29 D03.07
0x2a D04.00 0x2b D04.01
0x2c D04.02 0x2d D04.03
0x2e D04.04 0x2f D04.05
0x30 D04.06 0x31 D04.07
0x32 D04.08 0x33 D04.09
0x34 D04.10 0x35 D04.11
For instance: The register address of function parameter F03.02 is 0x0302, and that of function
parameter D01.01 is 0x3308.
8. Special instruction
1. For the data frame in ASCII mode, if the frame length is an even number, the frame is
abandoned.
2. Group F07, Group F10 and Group F14 (SCI communication parameters) are the controller
parameters which can be read but cannot be modified by the host computer.
3. If many multi-function input terminals setting are the same, it may cause dysfunction.
Therefore, the user should avoid this case when modify the multi-function terminal function via
the MODBUS.
B
