Appendix B Communication Protocol Shenzhen Hpmont Technology Co., Ltd
―142― HD5L Series Controller User Manual
2. To read the DC bus voltage of address 2 (to read state parameter D01.14)
Address Code Register address Word no. of read Checksum
0x02 0x03 0x33 0x15 0x00 0x01 0x9A 0Xb9
Corresponding answer frame (the DC bus voltage is 537V)
Address Code Answer byte Register content Checksum
0x02 0x03 0x02 0x02 0x19 0x3C 0xEE
3. To write the panel digital setting of address 2 (set F00.07 as 1.200m/s)
Address Code Register address Register content Checksum
0x02 0x41 0x00 0x07 0x04 0xB0 0x8F 0x43
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x41 0x00 0x07 0x04 0xB0 0x8F 0x43
4. Controller is at MS 2 up run of address 2.
Add. Code
Register
address
Register
number
Register
bytes No.
Register content Checksum
0x02 0x43 0x32 0x00 0x00 0x02 0x04 0x00 0x1D 0x00 0x02 0x53 0x3
Corresponding answer frame:
Address Code Register address Operate register number Checksum
0x02 0x43 0x32 0x00 0x00 0x02 0xCB 0x4F
5. Controller is at MS 2 down run of address 2.
Add. Code
Register
address
Register
number
Register
bytes No.
Register content Checksum
0x02 0x43 0x32 0x00 0x00 0x02 0x04 0x00 0x1F 0x00 0x02 0xF2 0xC3
Corresponding answer frame:
Address Code Register address Register content Checksum
0x02 0x43 0x32 0x00 0x00 0x02 0xCB 0x4F
