Hsun HS700UTV - Checking the Spark Plug

3-8
3. Install:
·console
·passenger seat
·driver seat
CHECKING THE SPARK PLUG
1. Lift the cargo bed up.
2. Remove:
pull out the spark plug cap ① and remove the spark
plug by sleeve
3. Check:
·spark plug type
Incorrect → Replace.
Standard spark plug
DPR8EA-9/NGK
4. Check:
·electrode ①
to check if it is burned blunt or much carbon is
there, then check the pole clearance by thickness
gauge. It is qualified if the pole clearance is between
0.6 to 0.7mm. Otherwise it should be adjusted.
Wear/damage → Replace.
·insulator ②
Abnormal color→ Replace.
Normal color is a medium-to-light tan color.
5. Clean the spark plug with a spark plug cleaner o
r
wire brush.
6. Install:
·spark plug
18 Nm -20 Nm (1.8 m · kg, 13 ft · lb)
Then hook up the spark plug cap.
Note :
Before installing a spark plug, clean the gasket
surface and plug surface.
7. Lower the cargo bed.
