Hsun HS700UTV - Changing the Final Gear Oil; Checking the Differential Gear Oil

3-28
WARNING:
Take care not allow foreign material to enter the final
gear case.
4. Install:
·oil filler plug
23 N.m (2.3 m · kg, 17 ft · lb)
CHANGING THE FINAL GEAR OIL
1. Place the vehicle on a level surface.
2. Place a container under the final gear case to collect
the used oil.
3. Remove:
·oil filler plug ①
·Fill:
final gear case
Periodic oil change
0.25 L (0.22 Imp qt)
Total amount
0.28 L (0.25 Imp qt)
WARNING:
Take care not to allow foreign material to enter the
final gear case.
·Install:
oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHECKING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Remove:
·oil filler plug ①
3. Check:
·oil level
Oil level should be up to the brim of hole.
Oil level low → Add oil to proper level.
WARNING:
Take care not allow foreign material to enter the
differential gear case.
4. Install:
