Hsun HS700UTV - Chassis Specifications

GENERAL SPECIFICATIONS
2-12
CHASSIS SPECIFICATIONS
Item Standard Limit
Steering system
Type Rack and pinion ----
Front suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
108 mm (4.25 in)
313 mm (12.32 in)
247.9 mm (9.76 in)
19.4 N/mm(1.94 kg/mm, 108.6 lb/in)
0 ~ 108 mm (0 ~ 4.25 in)
----
----
----
----
Rear suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
81 mm (3.19 in)
328 mm (12.91 in)
273.2 mm (10.76 in)
44.1 N/mm (4.41 kg/mm, 246.95 lb/in)
117.7N/mm (11.77kg/mm, 659.08 lb/in)
0 ~ 60 mm (0 ~ 2.36 in)
60 ~ 81 mm (2.36 ~ 3.15 in)
----
----
----
----
----
----
----
Front wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Panel wheel
12 ×6.0 AT
Steel
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
Rear wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Panel wheel
12×7.5 AT
Steel
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
Brake lever and brake pedal
Accelerator pedal free play
Brake pedal free play
Parking brake cable free play
0 mm (0.0 in)
0 mm (0.0 in)
2 ~ 3 mm (0.079 ~ 0.118 in)
----
----
----
