Hsun HS700UTV - Changing the Differential Gear Oil

3-29
·oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHANGING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Place a receptacle under the differential gear case.
3. Remove:
·oil filler plug①
4. Drain:
·differential gear oil
5. Install:
·drain plug
10 N.m (1.0 m · kg, 7.2 ft · lb)
Note:
Check the gasket (drain plug). If it is damaged,
replace it with new one.
6. Fill:
·differential gear case
Periodic oil change
0.32 L (0.28 Imp qt, 0.34 US qt)
Total amount
0.33 L (0.29 Imp qt, 0.35 US qt)
Note:
If gear oil is filled to the brim of the oil filler hole, oil
may start leaking from the differential gear case
breather hose. Therefore, check the quantity of the
oil, not its level.
WARNING:
Take care not to allow foreign material to enter the
differential gear case.
7. Install:
• oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
