Hsun HS700UTV - Checking the V-Belt

3-20
CHECKING THE V-BELT
1. Remove:
·driver seat
·
passenger seat
· console
·drive belt cover
·Check:
a. V-belt ①
Cracks/wear/scaling/chipping → Replace.
Oil/ grease→ Check primary sheave and secondary
sheave.。
b. V-belt width ②
Turn the main switch “ON”.
Coolant temperature warning light does
not come on.
Turn the main switch to “START” with
the transmission in neutral position.
Coolant temperature warning
light comes on
Coolant temperature and
electrical circuit are OK. Go
ahead with riding.
Coolant temperature warning
light come on momentarily.
Check the electrical circuit.
Coolant temperature
warning light does not
come on.
Coolant temperature warning light checking method
