CYLINDER HEAD

4-2

ENGINE REMOVAL

No. Name part Qty Remarks

Removing carburetor and intake

manifold.

Remove the parts in the order listed.

1 Carburetor 1

2 Carburetor joint (intake manifold) 1

3 Intake manifold 1

4 Drain plug 1

For installation, reverse the removal

procedure.
