Interface Attributes
Table 4-31 lists the interface attributes of the 8-Port 100/1000Base-RJ45 Physical Interface Card
(PIC).
Table 4-31 Interface attributes of the 8-Port 100/1000Base-RJ45 Physical Interface Card(PIC)
Attribute Value
Connector type RJ45
Working mode Full-duplex
Standard
compliance
IEEE802.3 ab
Frame format Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol IP
Specifications
Table 4-32 lists the technical specifications of the 8-Port 100/1000Base-RJ45 Physical Interface
Card(PIC).
Table 4-32 Specifications of the 8-Port 100/1000Base-RJ45 Physical Interface Card(PIC)
Item Specification
Silkscreen of
the board name
8xFE/GE-RJ
Typical power
consumption
12 W
Heat
dissipation
38.9 BTU/hour
Weight 0.43 kg (0.95 lb)
Dimensions (H
x W x D)
20 mm x 194 mm x 226 mm (0.79 in. x 7.64 in. x 8.90 in. )
Connector RJ45
Earliest
software
version
V800R005C00
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description
4 Boards
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
108
