Attribute Description
Cable
specification
8-core shielded cable
Table 1-28 lists the external clock interface attributes.
Table 1-28 Attributes of the external clock interface
Attribute Description
Connector type RJ45
Cable
specification
120-ohm clock shielded cable
Standard
compliance
G.703
Specifications
Table 1-29 lists the specifications of the MPUK.
Table 1-29 Specifications of the MPUK
Item Specification
Silkscreen of the board
name
CX-MPUK
Typical power
consumption
20 W
Heat dissipation 64.9 BTU/hour
Weight 0.6 kg ( 1.32 lb )
Dimensions (H x W x D) 20 mm x 194 mm x 226 mm (0.79 in. x 7.64 in. x 8.90 in. )
Earliest Software Version V800R005C01
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description 1 CX600-X1-M4 Hardware Description
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
27
