Huawei CX600-X2-M Series User Manual

Table 3-25 Description of the buttons and indicators on the MPU panel
Indicator/
Button
Description
STAT indicator If the indicator is steady green, the MPU is working properly.
If the indicator blinks green, the MPU is being registered.
If the indicator is steady red, the hardware of the MPU is faulty.
If the indicator is off, the MPU is not powered on or fails to be registered.
ACT indicator If the indicator is steady green, the MPU functions as the master MPU.
If the indicator is off, the MPU functions as the slave MPU or is not
registered.
ETH LINK
indicator
If the indicator is steady green, the ETH link is Up.
If the indicator is off, the ETH link is Down.
ETH ACT
indicator
If the indicator blinks yellow, data is being transmitted.
If the indicator is off, no data is being transmitted.
RESET button The button is used for resetting the MPU. Press the RESET button to
reset the MPU.
Table 3-26 Interfaces on the MPU
Interface
Name
Interface Type Description
ETH interface
(10M/100M/
1000M Base-
TX auto-
sensing)
RJ45 One ETH interface, for system maintenance
Console
interface
RJ45 One console interface, used to connect to the
console for on-site configuration
AUX interface
NOTE
User login by
using AUX
interfaces is not
supported at
present.This
interface is used
for reservation
expansion.
RJ45 One AUX interface, used to connect to the
modem for remote maintenance through a
dial-up connection
TOD date
interface
RJ45 Input or output 1PPS and TOD clock signals
from one channel, and input and output DCLS
from one channel
HUAWEI CX600-X1-M/CX600-X2-M Series Metro
Services Platform
Hardware Description 3 CX600-X2-M16 Hardware Description
Issue 03 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
84
