Procedure
Step 1 Open the front and rear doors of the cabinet.
Step 2 (Optional) Cut o the cable tie on the PAD cable in the cabinet, and pull the cable
into the cabinet through the front door.
Record the PAD cable route because you need to bind the PAD cable along the
original route in subsequent installation.
Figure 4-4 Removing the PAD cable
Step 3 Loosen the gas spring nuts using an adjustable wrench and remove the gas
springs.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 4 Installation Guide
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 62
