Procedure
Step 1 Open the rear door of the cabinet.
Step 2 Switch o the output circuit breaker of the power distribution subrack for the
PDU2000. Disconnect the power cables and signal cables from the PDU2000
terminal block.
Step 3 Remove the bolts that secure the PDU2000 using a Phillips screwdriver.
Step 4 Secure the new PDU2000 to the rear door of the cabinet.
Step 5 Reconnect the power cables or signal cables to the PDU2000, and switch on the
circuit breaker of the power distribution subrack.
----End
6.4.2 Replacing Power Supply and Distribution System
Components
● Only qualied personnel can replace components of the power supply and
distribution system.
● Wear protective tools such as insulation gloves and shoes before replacing a
power supply and distribution component.
● Power o the upper-level equipment before replacing a power supply and
distribution component.
● Use a multimeter and electrical tester pen to check whether the front and rear
ends of the component to be replaced are powered o after the component is
powered
o.
6.4.2.1 Replacing a Surge Protection Module
Prerequisites
● Do not replace a surge protection module during a thunderstorm.
● Before replacing a surge protection module, wear insulation gloves.
● Tools: insulation protective gloves, electroprobe
● Material: A new surge protection module of the same model is available and
functional.
Procedure
Step 1 Switch the SPD circuit breaker to OFF.
FusionModule500 Smart Mini Data Center
User Manual (Philippines, FusionModule500-
SU61A12S) 6 O&M
Issue 02 (2021-06-30) Copyright © Huawei Technologies Co., Ltd. 181
