Huawei FusionServer Pro XH321 V5 - Operating Temperature Limitations (Avago Sas3004 Imr RAID Controller Card + M.2 FRU Configured)

Drive
Backplane
Drive
Quantity (Q)
CPU Power
(P)
Maximum
Temperature
(Onboard
Optical
Module)
Maximum
Temperature
(PCIe Optical
Module)
X6000 V5 C10
12 x 3.5" SAS
backplane
8 < Q ≤ 12 165 W < P ≤
205 W
N/A N/A
140 W < P ≤
165 W
35°C (95°F) 30°C (86°F)
P ≤ 140 W 35°C (95°F) 30°C/86°F
(35°C/95°F
for 10GE
optical
modules)
4 < Q ≤ 8 165 W < P ≤
205 W
30°C (86°F) 30°C (86°F)
140 W < P ≤
165 W
35°C (95°F) 30°C (86°F)
P ≤ 140 W 35°C (95°F) 35°C (95°F)
0 < Q ≤ 4 165 W < P ≤
205 W
35°C (95°F) 30°C (86°F)
P ≤ 165 W 35°C (95°F) 35°C (95°F)
A.2.3 Operating Temperature Limitations (Avago SAS3004iMR
RAID Controller Card + M.2 FRU Congured)
Table A-4 Operating temperature specications (with Avago SAS3004iMR RAID
controller card + M.2 FRU congured)
Drive
Backplane
Drive Quantity
(Q)
CPU Power (P) Maximum
Temperature
X6000 V5 C00
24 x 2.5"
NVMe
backplane
16 < Q ≤ 24 140 W < P ≤ 165 W 28°C (82.4°F)
P ≤ 140 W 32°C (89.6°F)
8 < Q ≤ 16 140 W < P ≤ 165 W 30°C (86°F)
P ≤ 140 W 35°C (95°F)
0 < Q ≤ 8 140 W < P ≤ 165 W 35°C (95°F)
P ≤ 140 W 35°C (95°F)
