7.3 Cabling of the SATA Controller Integrated in the
Southbridge
Figure 7-3 Internal cabling for the SATA controller integrated in the southbridge
Table 7-3 Cabling of the SATA Controller Integrated in the Southbridge
No.
Huawei BOM
Code
Description
1 04052068 Signal cable for connecting the southbridge to the
Slimline connector
