7.4 PCIe Card Cabling
Figure 7-4 PCIe card cabling
Table 7-4 PCIe card cabling
No.
Huawei BOM
Code
Description
1 04080606 Signal cable for connecting the PCIe card to the
NC-SI connector
This cable is required only when the PCIe card is an SP380 NIC (BOM code: 02312JBD).
FusionServer Pro XH321 V5 Server Node
Maintenance and Service Guide 7 Internal Cabling
Issue 17 (2021-03-09) Copyright © Huawei Technologies Co., Ltd. 39
