Huawei UPS2000-G Series User Manual

UPS Mounting Ear Dimensions
Figure 3-3 Dimensions of the mounting ears for the 6 kVA/10 kVA UPS
Figure 3-4 Dimensions of mounting ears for the 15 kVA/20 kVA UPS
Clearances
NO TICE
The distance between UPS air vents and the wall or obstacle is greater than or
equal to 500 mm.
Reserve a clearance of at least 500 mm respectively from the front and rear panels
of the UPS to the wall or adjacent equipment to facilitate ventilation and heat
dissipation, as shown in Figure 3-5.
UPS2000-G-(6 kVA-20 kVA)
User Manual 3 Installation
Issue 21 (2022-10-13) Copyright © Huawei Technologies Co., Ltd. 35

Huawei UPS2000-G Series Specifications

General

Frequency	50/60 Hz
Output Power Factor	0.9
Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Capacity	1 kVA, 2 kVA, 3 kVA
Input Voltage	220 Vac (120 Vac/208 Vac/230 Vac/240 Vac)
Output Voltage	220/230/240 VAC
Efficiency	Up to 95%
Topology	Double conversion online
Battery Type	Sealed Lead Acid
Communication Ports	USB, RS232
Optional Communication	SNMP
Operating Temperature	0°C to 40°C
