Events
Type:—There are five available event types:
• Playback—broadcasts a previously configured message.
• Live Speech—broadcasts live audio.
• Record/Playback—records live audio for playback.
• Silent—activates outputs, output groups, or triggers an event chain. (No audio broadcast.)
• External—broadcasts externally generated audio.
Click the CREATE NEW EVENT OBJECT button after entering the description and selecting the event type
from the drop-down list. The EVENT BUILDER screen opens.
Event Builder
The event builder screen contains a parent section displaying the event’s root properties and six additional
panes to configure the event’s DEFAULT OUTPUT ASSIGNMENTS, DEFAULT AUDIO DESTINATIONS,
PLAYBACK EVENT OPTIONS, EVENT CANCEL, EVENT ACKNOWLEDGE, and EVENT CHAIN properties.
Building an event involves assembling all these components into a single action for execution by the
system.
Figure 81. Event Builder
Event Description—user-defined unique description.
Event Type—type of event. (See the Add Event section above.)
The EVENT OPTIONS pane located in the upper right corner of the EVENT BUILDER screen is
dependent upon the event type selected (see the Event Options section).
