Hughes 9502 - Terminal Specifications; Table 1 - Terminal Specifications

9502 User Guide
3004146-0001 Rev H
17
Terminal Specifications
Technical Specifications
Satellite TX Frequency
@ 1626.5 – 1675MHz
Satellite RX Frequency
@ 1518 – 1559 MHz
GPS Frequency
@ 1574.42 – 1576.42 MHz
9502 Indoor Unit Weight:
1.12 Kg
9502 Indoor Unit Dimensions:
150 mm x 200 mm x 45 mm
9502 External Antenna Weight:
1.85 Kg (exclude mount and cable)
9502 External Antenna Dimensions:
385 mm x 385 mm x 33 mm
Operating Temperature
-40
o
C to +75
o
C
Storage Temperature
-55
o
C to +75
o
C
Humidity
95% RH at +40
o
C
9502 External Antenna Wind loading
Survival wind loading (with optional mount) up to 100 mph
9502 Indoor Unit Water and Dust
IP-40 Compliant
9502 External Antenna Water and Dust
IP-65 Compliant
Nominal Input Voltage
+12VDC / +24VDC
Data Connectivity:
RJ45 connector (Ethernet 10BaseT)
USB –Type B (USB 1.1 for configuration PC)
Other Features:
Single external BGAN Satellite and GPS antenna connection
GPS module inside Indoor Unit
3 status LEDs
Antenna pointing audio tone and voltage level indicator
through audio jack
SIM/USIM Slot (behind SIM door)
Table 1 – Terminal Specifications
