9502 User Guide
3004146-0001 Rev H
Chapter 3 Operational Features
LEDs
The 9502 has three green LEDs:
Power LED: “PWR”
o Turn unit on - LED turns on
“GPS” LED
o Flashes while acquiring fix
o Turns solid when unit has a 2D or 3D fix
Network LED: “NET”
o Flashes when registered
o Turns solid when unit establishes a PDP context
All three LEDs flash in install mode and short flash if there is a
fault detected that prevents normal operation, e.g. no SIM installed
or incorrect SIM installed.
Function Button
The M2M unit includes one user button called the “function”
button.
Short press (< 2 second):
o During startup while power LED flashing, a short
press enters install mode (see Pg 53.)
o In install mode, short press exits install mode
o If LEDs off, short press turns them on
Medium press (2 to 5 seconds – the user should press and
hold for about 3 seconds):
o Shut down and reboot
Long press (> 5 seconds):
o Hardware power cycle
Network Mode
By default the 9502 is configured for NAT mode in the Network
Mode field on the IP Address/DHCP settings page.
