9502 User Guide
3004146-0001 Rev H
Insert the positive lead into the positive terminal jack and tighten
the screw. Then connect the negative lead into the negative
terminal jack and tighten the screw (see Figure 4-9 - Connecting
power leads).
Figure 4-9 - Connecting power leads
Important Note:
 Ensure the power source is turned off before connecting the power leads to the 9502 IDU
 Ensure that the screws are tightened to where the power leads cannot fall out
