Hughes 9502 - Figure 4-11 - Area Where the Ut May See 2 Satellites

9502 User Guide
3004146-0001 Rev H
55
With the introduction of MEAS, there are now parts of the
overlap areas of MEAS and EMEA, such as the yellow shaded
area below, where the antenna might be able to see a second
satellite.
Figure 4-11 – Area where the UT may see 2 satellites
During satellite switches, the satellite is turned off briefly and
the UT may try to register on the other satellite it can see. The
signal will be weaker and will degrade service so it is
advisable to select operation on a single satellite.
The visible satellites are shown on the status bar of the Home
page. To configure the UT to use a single satellite, use the
General Setup page (26) in release 5.9.5.0 and higher.
