Hunter Douglas Vignette Series User Manual

INSTALLATION
4
Left
Stack
Right
Stack
Split Stack
(Center Opening)
Installation Overview
Installation for Traversed
™
with Vertglide
™
Moveable Stack shades varies based on the shade’s
mounting type and the design to be installed.
Mounting Types and Window Terminology
■ Review the mounting types and basic window terminology illustrated below.
➤ There are different installation procedures for outside mount and inside mount shades.
➤ For ceiling mount applications, refer to the inside mount instructions.
Shade Designs
■ Determine which Traversed with Vertiglide Moveable Stack design you are installing: left
stack, right stack, or split stack (center opening).
Traversed with Vertiglide Moveable Stack Design
Primary
Moving Rails
Secondary
Rails
1 1
2 2
Trim or Molding
Floor or Sill
Jamb Jamb
Head
Jamb
Inside Mount
Shade fits within door
or window opening.
Outside Mount
Shade mounts outside
door or window opening.

Hunter Douglas Vignette Series Specifications

General

Series	Vignette
Operation	Manual or motorized
Fabric Options	Variety of colors and textures
Material	Fabric
UV Protection	Yes
Energy Efficiency	Yes (insulating properties vary by fabric)
