INSTALLATION
4
Installation Overview
■ Your order will include the correct number of installation brackets for your shade width, as
shown in the table below.
Mounting Types and Window Terminology
If the installation brackets are mounted correctly, the rest of the installation process follows
easily. To prepare for this important first step, review the mounting types and basic window
terminology illustrated below.
■ Refer to the appropriate page below based on your order:
➤ Inside Mount — Page 5
➤ Outside Mount — Page 6
➤ End Mount — Page 8
Bracket
Shade Width
Brackets
Required
12" – 38" 2
38
1
/
8
"
–
72" 3
72
1
/
8
" – 96" 4
96
1
/
8
" – 120" 5
120
1
/
8
" – 140" 6
Outside Mount
Shade mounts outside
window opening.
Inside Mount
Shade fits within
window opening.
Collectively, the sill and
jambs are called the
“window casement.”
Head Jamb
Sill
Jamb Jamb
