Hunter HD Elite - Power Switch

NOTE
For information on converting from single phase NEMA L6-20P plug to thee phase NEMA LHDElite5-20P plug
refer to Form 5350-T
OPTICAL SCAN LASER
The Optical Scan Laser is a class HD Elite laser designed to measure the prole of wheel assemblies. The laser is not a eld
serviceable part. No maintenance is to be performed on the laser.
Wavelength: 650nm.
HAMMERHEAD® TDC LASER INDICATOR (Optional)
The TDC (Top Dead Center) Laser Indicator is a class2M laser designed to aid in applying clip-on weights. The laser is not a
eld serviceable or adjustable part.
Use caution in regard to reective materials around the laser and
never look into the laser beam.
LASER RADIATION - DO NOT STARE INTO THE BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.
Viewing the laser output with magniers or related optical
instruments within a distance of 100mm from the laser aperture may
pose an eye hazard.
1.6. Power Switch
TURNING POWER ON/OFF
Push Button
The HD Elite power button is located on the left side of
the LCD support. Use this switch for normal shut down
and restarting procedures.
MAIN POWER SWITCH
HD Elite Wheel Balancer
Page 7 of 51
